Solar Power System 3kw Inverter / 5000va for Home 48V- AC 110V 220V 230V 240V Pure Sine Wave

Foshan Tanfon Energy Technology Co., Ltd. Is specialized in R&D, manufacturing and selling solar power system product, wind power system product, solar &wind hybrid system(on grid and off grid systems). Product sales to (France, USA, Canada, Pakistan, Indonesia, UAE, Bangladesh,
Philippines, Greece, Iran, Kuwait, Iraq, Bulgaria, Roumania, South Africa ect)
More and more homeowners are looking forward to Solar Power for Homes so as to increase energy-efficiency in their homes. Solar power, in addition to cutting out pollution, also provides personal as well as national energy security because it reduces energy bills and any nation's reliance on imported fuel. When it comes to using Solar Power for Homes, it is not just about installation of solar panels on your roof. It would also mean the upgrading of the water heating system, application of green building design concepts or remodeling the home
These modules have the following positive features:
They require minimal amount of maintenance
They are exceptionally durable
They are designed to last a lifetime
We accept OEM and small trial orders, contacting with us now for more information. All inquiries will be replied with in 24 hours
Good quality, best price and better technical support and service, make Tanfon energy technology Co., Ltd as your most valuable cooperator in China.

Pure sine wave home inverter/solar,wind system off grid inverter Feature:
1) super wide input voltage: 160V---280VAC
2) completely controlled by CPU. Battery temperature sensor (BTS) Automatic generator starting (AGS)
3) protect against output short-circuit/overload. When you throw off its load, it will turn on automatically.
4) optional for charge build-in, charge current is 10A----30A.
5) different DC voltage: 12V, 24V, 36V, 48V, 96V, 110V,192V, 240V for optional.
6) inverter can operate with 120% of nominal load during 1 minute ;150% of nominal load during 10 second.
7) it can drive inductive loads, such as lightings, TV sets, fans, refrigerators and air-conditioner
8) it's humanized design, when the AC comes, it will start the unit automatically; And when it overload, it will also close the unit automatically, when you cancel the load, then it will return to work automatically.
9) ATM inverter, RS232 software, SNMP card for optional.
10)have double protection ,city power &battery switch.

Model    TF300W    TF500W    TF700W
Capacity(W)    300W    500W    700
DC voltage(V)    12/24    12/24    12/24
Input voltage(V)    160-265VAC
Input frequency     45-65HZ
Output voltage    Four steps AVR, 110V/120V/220V/230V for optional
Output wave form    Pure sine wave
THD    ≤ 3%
Low-voltage protection(V)    9.8/19    9.8/19    9.8/19
Over voltage protection(V)    15/30    15/30    15/30
Recharge current    5-10A    5-10A    5-10A
Unit size(mm)    348*122*200    348*122*200    370*122*200
Transfer efficiency    87%--90%
Protections    Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection
Over load    120% of the rate capacity
Short circuit    300% of the rate capacity


Model    TF1K    TF1.5K    TF2K
Capacity(W)    1000    1500    2000
DC voltage(V)    24/48    24/48    24/48
Input voltage(V)    160-265VAC
Input frequency     45-65HZ
Output voltage    Four steps AVR, 110V/120V/220V/230V for optional
Output wave form    Pure sine wave
THD    ≤ 3%
Low-voltage protection(V)    19/39    19/39    19/39
Over voltage protection(V)    30/60    30/60    30/60
Recharge current    10-15A    10-15A    10-15A
Unit size(mm)    388*145*210    446*175*300    446*175*300
Transfer efficiency    87%--90%
Protections    Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection
Over load    120% of the rate capacity
Short circuit    300% of the rate capacity


Model    TF3K    TF4K    TF5K    TF6K
Capacity(W)    3000    4000    5000    6000
DC voltage(V)    48    48/96    48/96    48/96
Input voltage(V)    160-265VAC
Input frequency     45-65HZ
Output voltage    Four steps AVR, 110V/120V/220V/230V for optional
Output wave form    Pure sine wave
THD    ≤ 3%
Low-voltage protection(V)    39/78    39/78    39/78    39/78
Over voltage protection(V)    60/120    60/120    60/120    60/120
Recharge current    15-25A    15-25A    15-25A    20-30A
Unit size(mm)    473*220*386    473*230*490
Transfer efficiency    87%--90%
Protections    Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection
Over load    120% of the rate capacity
Short circuit    300% of the rate capacity

Model    TF10K    TF15K    TF20K    TF30K
Capacity(W)    10000    15000    20000    30000
DC voltage(V)    96    96/240    240/384    384
Input voltage(V)    160-265VAC
Input frequency     45-65HZ
Output voltage    Four steps AVR, 110V/120V/220V/230V for optional
Output wave form    Pure sine wave
THD    ≤ 3%
Low-voltage protection(V)    78    78/216    216/322    322
Over voltage protection(V)    120    120/272    272/480    480
Recharge current    20-30A    30-40A    without    without
Unit size(mm)    560*280*680    560*320*700    900*600*1380    900*600*1380
Transfer efficiency    87%--90%
Protections    Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection
Over load    120% of the rate capacity
Short circuit    300% of the rate capacity
