Home > Products > Inverter > Power Inverter > 12V 24V DC to 120V/220/ 230V AC Home Solar Power Inverter
12V 24V DC to 120V/220/ 230V AC Home Solar Power Inverter
12V 24V dc to 120v/220/230v ac home solar power inverterPure Sine Wave Inverter Dark Star Series 600Va-1200Va (1ph in/1ph out) DS 600VA-1200VAKey Features:1:CPU controlled2:LCD display with plenty content3:Fast transfer time,high efficiency4:CPU core PWM pulse width control technology5:Low battery,......
Send Inquiry
Product Description
12V 24V dc to 120v/220/230v ac home solar power inverter
Pure Sine Wave Inverter Dark Star Series 600Va-1200Va (1ph in/1ph out) DS 600VA-1200VA
Key Features:
1:CPU controlled
2:LCD display with plenty content
3:Fast transfer time,high efficiency
4:CPU core PWM pulse width control technology
5:Low battery,overload short circuit,over temperature protections
6:Intelligent battery management,prolonging the service life of the battery
7:Components with high-quality original, ensure products with high quality
8:Durable construction for long life under extreme environmental conditions
9:Stable output voltage(pure sine wave output),can be applied to all electrical equipment
10:High-definition LCD display: adopted high quality LCD display, can clearly see the data from different angles
11:Featured with high reliability and low failure rate by using the advanced double-CPU single chip intellectual control technology
Applications
vacuum cleaners, fans, Electronic energy-saving fluorescent, incandescent, small television sets, refrigerator,shavers,sewing machines,air conditions,coffee makers,blenders,ice markers,toasters etc.
Technical Specification
Pure Sine Wave Inverter Dark Star Series 600Va-1200Va (1ph in/1ph out) DS 600VA-1200VA
Key Features:
1:CPU controlled
2:LCD display with plenty content
3:Fast transfer time,high efficiency
4:CPU core PWM pulse width control technology
5:Low battery,overload short circuit,over temperature protections
6:Intelligent battery management,prolonging the service life of the battery
7:Components with high-quality original, ensure products with high quality
8:Durable construction for long life under extreme environmental conditions
9:Stable output voltage(pure sine wave output),can be applied to all electrical equipment
10:High-definition LCD display: adopted high quality LCD display, can clearly see the data from different angles
11:Featured with high reliability and low failure rate by using the advanced double-CPU single chip intellectual control technology
Applications
vacuum cleaners, fans, Electronic energy-saving fluorescent, incandescent, small television sets, refrigerator,shavers,sewing machines,air conditions,coffee makers,blenders,ice markers,toasters etc.
Technical Specification
| Model | DS600 | DS800 | DS1000 | DS1200 | DS600 Plus | DS800 Plus | DS1000 Plus | DS1200A Plus |
| Capacity | 480W | 640W | 800W | 1000W | 480W | 640W | 800W | 1000W |
| Power factor | 0.8 | |||||||
| AVR | No | 3 steps of AVR, CPU controlled | ||||||
| INPUT | ||||||||
| Input voltage range | Inverter mode: 80~290Vac±5Vac (Inverter mode) | 145~270Vac±5Vac | ||||||
| UPS mode: 175~270Vac±5Vac (UPS mode) | ||||||||
| OUTPUT | ||||||||
| Output voltage range | 80~290Vac±5Vac, Same as AC (AC mode) 220Vac±5% (DC mode) | 203~238±5Vac | ||||||
| 175~270Vac±5Vac, Same as AC(AC mode) 220Vac±5% (DC mode) | ||||||||
| Output frequency | 50Hz ±5Hz (DC mode) | |||||||
| Wave form | Sine wave (DC Mode) | |||||||
| Transfer time | Max. 10s. | |||||||
| BATTERY | ||||||||
| QTY & capacity of battery | DC 12V | DC12V /24V | DC 12V | DC12V /24V | ||||
| Charging current | 15A | 15A | 20A | 20A | 15A | 15A | 20A | 20A |
| PROTECTION & FUNCTION | ||||||||
| PROTECTION | 1. Battery low voltage protection 2. Overload protection 3. Short circuit protection | |||||||
| FUNCTION | 1. Auto re-starts when AC recovers 2. Silence setup 3. Automatic charging (offline charging) 4.Combined UPS mode and inverter mode. | |||||||
| MANAGEMENT | ||||||||
| USB | Optional (Note: Funciton of combined UPS and inverter mode is disabled if USB is required.) | Optional ( (Note: Funciton of optional charging current is disabled if USB is required.) | ||||||
| PHYSICAL | ||||||||
| Unit dimension (mm) | 290*255*120 | |||||||
| Color box dimension (mm) | 340*130*205 | |||||||
| Master box dimension (mm) | 355*325*435 | 355*325*225 | 355*325*435 | 355*325*225 | ||||
| Pcs in one master carton | 2 | 1 | 1 | 1 | 2 | 1 | 1 | 1 |
| Gross weight (1pc, kg) | 7.6 | 11.4 | 12.0 | 13.6 | 7.6 | 11.4 | 12.0 | 13.6 |
| Net weight (1pc, kg) | 7 | 10.8 | 11.4 | 13 | 7 | 10.8 | 11.4 | 13 |
