Cbb60 Motor Run Power Capacitor
Detailed Product Description:1. Used widely in motors, fans. 2. High performance & Long life Capacitor. 3. Work well even in hot area. Main Feature:Low dissipation factor,small inherent temperature rise.excellentself-healing stability,safety and high voltage withstand,etc. Applications:To start ......
Send Inquiry
Product Description
Detailed Product Description:
1. Used widely in motors, fans.
2. High performance & Long life Capacitor.
3. Work well even in hot area.
Main Feature:
Low dissipation factor,small inherent temperature rise.excellent
self-healing stability,safety and high voltage withstand,etc.
Applications:
To start and run single phase motors in alternating current usage.
1. Used widely in motors, fans.
2. High performance & Long life Capacitor.
3. Work well even in hot area.
Main Feature:
Low dissipation factor,small inherent temperature rise.excellent
self-healing stability,safety and high voltage withstand,etc.
Applications:
To start and run single phase motors in alternating current usage.
| #CBB61 Motor run capacitor: | ||
| Capacitance Range | 1μF~30μF | |
| Rated Voltage | 250VAC~500VAC(50/60Hz) | |
| Capacitance Tolerance | ±5% or Fulfilled upon request | |
| Loss Tangent | Tgδ≤0.002(50Hz-100Hz) | |
| Standard Temperature | -25ºC~+70ºC,-40ºC~+85ºC | |
| Climate Class | 25/70/21, 40/85/21 | |
| Test Voltage | Between terminals | AC≥2.00Un 2S NO BREAKDOWN |
| Between terminals and case | AC≥2000V 2S NO BREAKDOWN | |
| Insulation Resistance | Between terminals | Rj·C≥3000MΩ.μF |
| Between terminals and case | Rj≥1000 MΩ.μF | |
| Security Level | P0, P1, P2 | |
| Executing Standard | GB/T3667.1-2005, IEC60252-1:2001, IEC252 | |
