Compatible Lemos 1p RM-Plg- M0 -6gll High Quality Equivalent Lemos Circular Connector

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED , here in after referred to as the " RAYMO", As a "Creative customer -oriented" manufacturer located in Shenzhen, focusing on manufacturing metal and plastic circular push pull connectors and cable assemblies to serve over 75 countries and regions since 2010. Products can be 100% compatible with original ones(LEMOS,FISCHERS,HIROSE,BINDERS ODU SRIES).


With professional R&D and excellent craftsmanship, our factory has the ability of offering customer with much more precision connectors and cable harness solution to meet customer's real needs in his field.

RAYMO has already established an integrated quality control system from R&D, Supply Chain, Marketing sales ,after sales service to achieve Raymo's globalization stratege .

Part No.:
RM-PLG-1P-304-KS


Description:
1Pseries , Straight plug, 0 degree, male contacts ,4 pins, outer shell in grey, in solder type,grey back nut



Technical Characteristics :
Endurance: 5,000 mating cycles (shell)
Humidity: <95% at 60 deg. C/140 deg. F (maximum)
Pop (maximum): 60 bar (870psi)
Temperature: -55 deg. C minimum(-20 deg. C maximum for watertight)
Temperature: 250 deg. C maximum(100 deg. C maximum for watertight)
Resistance to vibration:10-2000Hz,15g
Shock resistance: 100g (6ms)
Salt spray corrosion test:>72h
Protection grade: IP50
Climatical category:55/175/21
Shielding (min): 75 dB (10 MHz)
Shielding (min): 40 dB (1 GHz)
Note:the various tests have been carried out with FGG and EGG connector pairs ,with chrome-plated brass shell and PPS insulator.
