A vehicle electrical design engineer is calculating the dark current budget for a new model. The target is 20 mA total when the vehicle is parked and locked. The seat memory module alone is drawing 12 mA because it uses a standard single-coil Automotive Relay that must remain energized to keep the memory position stored. The engineer replaces the single-coil relay with a dual-coil latching relay. The holding current drops to zero. The seat memory module now draws only 0.5 mA in sleep mode. The engineer recalculates the total dark current: 8.5 mA, well within the target. This guide explains how dual-coil latching relays achieve zero holding current and why that matters for memory applications.
A standard single-coil Automotive Relay requires continuous current through the coil to keep the contacts closed. For a memory application, the relay must stay closed for weeks or months while the vehicle is parked. The coil current is typically 100 to 200 mA for a 12V relay. Even with a duty cycle reduction circuit, the average holding current is 10 to 50 mA. This current drains the battery. The table below shows the battery drain for different holding currents over a 30-day parking period.
| Holding current (mA) | Drain over 30 days (Ah) | Battery capacity remaining (60 Ah battery) | Engine start risk |
| 50 | 36 | 40% | High |
| 30 | 21.6 | 64% | Moderate |
| 10 | 7.2 | 88% | Low |
| 1 | 0.72 | 98.8% | Very low |
| 0 (latching) | 0 | 100% | None |
In our factory, we manufacture Automotive Relay units for both standard and latching configurations. The dual-coil latching relay is designed for applications that require the contact state to be maintained without continuous power. Ningbo Forward Relay Corp., Ltd. has been manufacturing automotive relays for over 18 years.
A dual-coil latching relay has two separate coils: a set coil and a reset coil. The set coil is energized momentarily to close the contacts. The reset coil is energized momentarily to open the contacts. Once the contacts are in position, they are held by a permanent magnet. No current is required to maintain the state. The pulse duration is typically 20 to 50 milliseconds. The table below compares the operating characteristics of a standard relay and a dual-coil latching relay.
| Parameter | Standard single-coil relay | Dual-coil latching relay |
| Coil current to close | 150 mA continuous | 400 mA for 30 ms (pulse) |
| Coil current to hold | 150 mA | 0 mA |
| Energy per operation | 1.8 J (continuous) | 0.14 J (pulse) |
| Contact state on power loss | Opens (de-energized) | Remains in last state |
| Battery drain in sleep mode | 10 – 50 mA | 0 mA |
| Typical life | 100,000 operations | 100,000 operations |
Design engineer's note: The pulse energy is much lower than the continuous energy of a standard relay. The dual-coil latching relay draws 400 mA for 30 ms, which is 0.14 joules. A standard relay drawing 150 mA continuously for the same 30 ms would draw 0.0054 joules, but it would continue drawing that current indefinitely. The key advantage is the zero holding current. In a memory application, the relay may be in one state for months. The zero holding current eliminates the battery drain entirely. In our factory, we test the pulse energy and the holding force of every latching relay batch to ensure consistent performance.
Dual-coil latching relays are used in four common memory applications in vehicles. The first is seat position memory. The relay stores the seat position by maintaining the connection to the memory module. The second is mirror position memory. The relay maintains the mirror angle setting. The third is clock and radio preset memory. The relay keeps the memory backup circuit alive. The fourth is HVAC setting memory. The relay maintains the last temperature and fan speed settings. The table below shows the application, the typical relay configuration, and the holding current saved.
| Memory application | Relay configuration | Holding current saved | Battery drain avoided (30 days) |
| Seat position memory | DPDT dual-coil latching | 15 mA | 10.8 Ah |
| Mirror position memory | SPDT dual-coil latching | 8 mA | 5.8 Ah |
| Clock and radio preset | SPST dual-coil latching | 5 mA | 3.6 Ah |
| HVAC setting memory | SPDT dual-coil latching | 10 mA | 7.2 Ah |
In our factory, we manufacture dual-coil latching Automotive Relay units in SPST, SPDT, and DPDT configurations. The relays are sealed and rated for the engine compartment temperature range of -40°C to +125°C. Ningbo Forward Relay Corp., Ltd. supplies these relays to seat module manufacturers and body control module suppliers.
The design engineer must consider four factors when using a dual-coil latching relay. The first is the pulse drive circuit. The relay requires a short, high-current pulse. The driver must be able to supply 400 mA for 30 ms. A capacitor discharge circuit or a dedicated driver IC is typically used. The second is the state feedback. The relay does not provide a direct indication of its state. The designer must use an auxiliary contact or a software flag to track the state. The third is the fail-safe behavior. If the vehicle battery is disconnected, the relay remains in its last state. This is desirable for memory applications but may not be desirable for safety-critical functions. The fourth is the coil resistance tolerance. The pulse current depends on the coil resistance, which varies with temperature. The driver must be designed to supply the required current over the full temperature range. The table below summarizes these considerations.
| Design consideration | Requirement | Typical solution |
| Pulse drive | 400 mA for 30 ms | Capacitor discharge or driver IC |
| State feedback | Determine if relay is set or reset | Auxiliary contact or software flag |
| Fail-safe | Defined behavior on power loss | Use latching only for non-safety functions |
| Coil resistance tolerance | Maintain pulse current over temperature | Constant current driver or PWM |
In our factory, we provide the coil resistance versus temperature curve for each latching relay model. We also provide a recommended driver circuit and a state feedback circuit. Ningbo Forward Relay Corp., Ltd. offers application support for designers who are transitioning from standard relays to latching relays.
Dual-coil latching Automotive Relay units provide latching functionality for memory applications by using a permanent magnet to hold the contact state after a short pulse. The zero holding current eliminates the dark current drain that would otherwise deplete the battery over time. The relay is suitable for seat memory, mirror memory, clock memory, and HVAC memory applications. The design engineer must consider the pulse drive circuit, the state feedback, the fail-safe behavior, and the coil resistance tolerance. By selecting the right latching relay and driver circuit, the engineer can achieve a reliable memory function with minimal battery drain. Ningbo Forward Relay Corp., Ltd. has been manufacturing automotive relays for over 18 years and provides full application support for latching relay designs.
