Where Can I Find the Datasheet and Tripping Curves for the NH2 XL 1500VDC gPV Fuse
2026-06-09
For engineers designing 1500V photovoltaic systems, locating the official datasheet and time-current tripping curves for the NH2 XL 1500VDC gPV Fuse is a common challenge. Yinrong provides full technical documentation for this fuse series through multiple verified channels.
Technical Data Overview
The table below summarizes key specifications found in the NH2 XL 1500VDC gPV Fuse datasheet:
| Parameter | Typical Value |
|---|---|
| Rated Voltage | 1500VDC |
| Current Range | 10A - 125A |
| Breaking Capacity | 30kA (min) |
| Standard Compliance | IEC 60269-6 (gPV) |
| Operating Temperature | -40°C to +90°C |
How to Access Documents from Yinrong
-
Yinrong website → Products → NH2 XL 1500VDC gPV Fuse → Datasheet / Curves
-
Authorized distributors: DigiKey, Mouser, TME
-
Direct request: [email protected] with model number
NH2 XL 1500VDC gPV Fuse - FAQ
Q1: What information is included in the NH2 XL 1500VDC gPV Fuse tripping curves?
A1: The tripping curves from Yinrong show minimum and maximum clearing times from 0.01 to 1000 seconds, plotted against current multiples (1x to 10x rated current). Each curve includes temperature correction factors for 25°C, 60°C, and 85°C ambient conditions.
Q2: Are the NH2 XL 1500VDC gPV Fuse datasheets available in multiple languages?
A2: Yes. Yinrong provides datasheets for the NH2 XL 1500VDC gPV Fuse in English, German, and Chinese. All versions include identical electrical specifications and tripping curves to avoid translation discrepancies.
Q3: How often does Yinrong update the NH2 XL 1500VDC gPV Fuse technical documents?
A3: Yinrong reviews and revises NH2 XL 1500VDC gPV Fuse documentation every 12 months or after any manufacturing process change. Each document displays a revision date and version number. Users can subscribe to update notifications via the product page.
Coordination Checklist
-
Verify breaking capacity matches system fault current
-
Compare tripping curves with upstream protection devices
-
Request batch-specific test certificates from Yinrong for large projects
Contact Us
For immediate access to datasheets or customized tripping curves for the NH2 XL 1500VDC gPV Fuse, reach out to Yinrong or use the contact form on the official website. Engineering support replies within 24 hours.
